Getting Started
Everything you need to get started with your DR750G-2CH can be found in the links below.
Getting stuck operating your BlackVue camera or attempting to perform a certain function? Check out our App Support and Camera Support categories which have a collection of detailed how-to guides and troubleshooting available.
Want to know what accessories are compatible with the DR750G-2CH? Check out our Accessory Compatibility List.
 |
|
|
|
|
| DR750G-2CH - Quick Start Guide | App Support | Camera Support | Accessory Compatibility List | Frequently Asked Questions |
Firmware
| Latest BlackVue Firmware | |
|
What's new:
|
Released: 01/12/2021 |
Warranty
All BlackVue Gold series cameras purchased in Australia from authorised BlackVue dealerships come with a 5-year limited hardware warranty from the original date of purchase, with the option to register your purchase via the link below.
In the unlikely event you experience a hardware fault with your camera, you can contact your original dealership or raise a warranty or out of warranty claim with us below.
Recording Timetable
| Model | Memory Capacity | Image Quality | Resolution/Recording Time | |||
| DR750G-2CH | Full HD @60 + Full HD @30 |
Full HD @30 + Full HD @30 |
Full HD @30 + HD @30 |
HD @30 + HD @30 |
||
| 16GB | Extreme | 55 Min | X | X | X | |
| Sports | 1 HR 25 Min | X | X | X | ||
| Highest | X | 1 HR 25 Min | 1 HR 35 Min | 2 HR | ||
| High | X | 1 HR 50 Min | 2 HR | 2 HR 40 Min | ||
| Normal | X | 2 HR 20 Min | 2 HR 40 Min | 4 HR | ||
| 32GB | Extreme | 1 HR 50 Min | X | X | X | |
| Sports | 2 HR 50 Min | X | X | X | ||
| Highest | X | 2 HR 50 Min | 3 HR 10 Min | 4 HR | ||
| High | X | 3 HR 40 Min | 4 HR | 5 HR 20 Min | ||
| Normal | X | 4 HR 40 Min | 5 HR 20 Min | 8 HR | ||
| 64GB | Extreme | 3 HR 40 Min | X | X | X | |
| Sports | 5 HR 40 Min | X | X | X | ||
| Highest | X | 5 HR 40 Min | 6 HR 20 Min | 8 HR | ||
| High | X | 7 HR 20 Min | 8 HR | 10 HR 40 Min | ||
| Normal | X | 9 HR 20 Min | 10 HR 40 Min | 16 HR | ||
| 128GB | Extreme | 7 HR 20 Min | X | X | X | |
| Sports | 11 HR 20 Min | X | X | X | ||
| Highest | X | 11 HR 20 Min | 12 HR 40 Min | 16 HR | ||
| High | X | 15 HR 40 Min | 16 HR | 21 HR 20 Min | ||
| Normal | X | 18 HR 40 Min | 21 HR 20 Min | 32 HR | ||
| 256GB | Extreme | 14 HR 40 Min | X | X | X | |
| Sports | 22 HR 40 Min | X | X | X | ||
| Highest | X | 22 HR 40 Min | 25 HR 20 Min | 32 HR | ||
| High | X | 29 HR 20 Min | 32 HR | 42 HR 40 Min | ||
| Normal | X | 37 HR 20 Min | 42 HR 40 Min | 64 HR | ||
|
Bitrate (Mbps) Front + Rear |
Extreme | 25 + 10 | X | X | X | |
| Sports | 12 + 10 | X | X | X | ||
| Highest | X | 12 + 10 | 12 + 8 | 8 + 8 | ||
| High | X | 10 + 8 | 10 +6 | 6 + 6 | ||
| Normal | X | 8 +6 | 8 +4 | 4 + 4 | ||
*Actual recording times may vary
Specifications
Model Name |
DR750G-2CH |
Colour / Size / Weight |
Front: Black / Width 118.5 mm x Height 36 mm / 90 g Rear: Black / Width 67.4 mm x Height 25 mm / 25 g |
Memory |
microSD Card (32 GB / 64 GB / 128 GB / 256 GB) *We only recommend using BlackVue SD cards |
Recording Modes |
Normal recording, Event recording (when impact is detected in normal and parking mode), Manual recording (File locked) and Parking recording (when motion is detected) *When using Hardwiring Power Cable, ACC+ will trigger parking mode. When using other methods, G-sensor will trigger parking mode. |
Camera |
Front: STARVIS™ CMOS Sensor (Approx. 2.1 M Pixel) Rear: STARVIS™ CMOS Sensor (Approx. 2.1 M Pixel) |
Viewing Angle |
Front: Diagonal 139°, Horizontal 116°, Vertical 61° Rear: Diagonal 139°, Horizontal 116°, Vertical 61° |
Resolution/Frame Rate |
<Front> - <Rear> Full HD (1920x1080) @ 60 fps - Full HD (1920x1080) @ 30 fps (Extreme) Full HD (1920x1080) @ 60 fps - Full HD (1920x1080) @ 30 fps (Sports) Full HD (1920x1080) @ 30 fps - Full HD (1920x1080) @ 30 fps Full HD (1920x1080) @ 30 fps - HD (1280x720) @ 30 fps HD (1280x720) @ 30 fps - HD (1280x720) @ 30 fps *Frame rate may vary during Wi-Fi streaming. |
Image Quality |
Highest, High, Normal |
Video Compression Mode |
MP4 |
Wi-Fi |
Built-in (802.11n (2.4 − 2.4835 GHz)) |
GPS |
Built-in |
Microphone |
Built-in |
Speaker (Voice Guidance) |
Built-in |
LED Indicators |
Front: Recording LED, GPS LED, Wi-Fi LED, Front Security LED Rear: Rear Security LED |
Button |
Wi-Fi / Format button: Press once to turn on/off Wi-Fi. Press and hold for 5 seconds and once voice commands start, release the button. Then press once Proximity sensor: Touching the proximity sensor turns on/off audio recording or triggers manual recording depending on the firmware settings. |
Sensor |
3-Axis Acceleration Sensor |
Battery or Capacitor |
Built-in Super Capacitor |
Input Power |
DC 12 V - 24 V (DC Plug: (Ø3.5 x Ø1.35), MAX 1 A/12 V) |
Power Consumption |
Avg. 350 mA (4.2 W at 12 V, when GPS and Wi-Fi is On) Avg. 300 mA (3.6 W at 12 V, when GPS and Wi-Fi is Off) *Actual power consumption may vary depending on use conditions and environment. |
Operation Temperature |
-20°C − 70°C (-4°F − 158°F) |
Storage Temperature |
-20°C − 70°C (-4°F − 158°F) |
High Temperature Cut-Off |
Approx. 80°C (176°F) |
Certifications |
Front: CE, RoHS, WEEE Rear: FCC, CE, RoHS, WEEE |
Software |
BlackVue Viewer: Windows XP or higher and Mac Yosemite OS X (10.10) or higher |
Application |
BlackVue Application: (Android 4.4.2 or higher, iOS 9.0 or higher) |
Others |
Adaptive Format Free File Management System Advanced Driver Assistance System LDWS (Lane Departure Warning System) FVSA (Forward Vehicle Start Alarm) |
Origin |
Made in Korea |
Warranty |
60 Months Warranty (Dealership Customers Only) *T&C's Apply |
STARVIS is a trademark of Sony Corporation
