Resolution/Recording Time

(Front + Rear + Optional)

Front: Full HD @60fps

Rear: Full HD @30fps

Interior: Full HD @30fps

Model Name

DR770X Box Pro

Colour / Size / Weight

Main unit: Black / Length 135.0 mm x Width 101.0 mm x Height 37.5 mm / 225 g

Front: Black / Length 77.5 mm x Width 34 mm x Height 49.5 mm / 61 g

Rear (optional): Black / Length 69.5 mm x Width 32.0 mm x Height 48.3 mm / 46 g

Rear Truck (optional): Black / Length 81 mm x Width 56.6 mm x Height 51 mm / 220 g

Interior IR (optional): Black / Length 69.5 mm x Width 32.0 mm x Height 48.3 mm / 47 g

EB-1: Black / Length 45.2 mm x Width 42.0 mm x Height 14.5 mm / 23 g

Memory

microSD Card (64 GB / 128 GB / 256 GB / 512 GB)

*We only recommend using BlackVue SD cards

Recording Modes

Normal recording, Event recording (when impact is detected in normal and parking mode), Manual recording and Parking recording (when motion is detected).

*When using Hardwiring Power Cable, ACC+ will trigger parking mode. When using other methods, G-sensor will trigger parking mode.

Camera

Front: STARVIS™ CMOS Sensor (Approx. 2.1 M Pixel)

Rear/Rear Truck: STARVIS™ CMOS Sensor (Approx. 2.1 M Pixel)

Interior IR: STARVIS™ CMOS Sensor (Approx. 2.1 M Pixel)

Viewing Angle

Front (FC1): Diagonal 139°, Horizontal 116°, Vertical 61°

Rear (RC1): Diagonal 139°, Horizontal 116°, Vertical 61°

Rear Truck (ERC1): Diagonal 116°, Horizontal 97°, Vertical 51°

Interior IR: Diagonal 180°, Horizontal 150°, Vertical 93°

Resolution / Frame Rate

Front (FC1): Full HD (1920×1080) @ 60 fps

Rear (RC1): Full HD (1920×1080) @ 30 fps

Rear Truck (ERC1): Full HD (1920×1080) @ 30 fps

Interior IR: Full HD (1920×1080) @ 30 fps

*Frame rate may vary during Wi-Fi streaming.

Video Codec

H.264 (AVC)

Image Quality (Mbps)

Extreme: 16 + 10 + 10 Mbps

Highest: 12 + 10 + 10 Mbps

High: 10 + 8 + 8 Mbps

Normal: 8 + 6 +6 Mbps

Video Compression Mode

MP4

Wi-Fi

Built-in (802.11 b.g.n)

GPS

External (Dual Band: GPS, GLONASS)

Bluetooth

Built-in (V2.1+EDR/4.2)

4G LTE

Optional via the CM100GLTE module

Microphone

Built-in

Speaker (Voice Guidance)

Built-in

LED Indicators

Main unit: Recording LED, GPS LED, BT/Wi-Fi/LTE LED

Front: Front & Rear Security LED

Rear:  Front & Rear Security LED

Rear Truck: none

Interior IR: Front & Rear Security LED

EB-1: Operating/Battery low voltage LED

Wavelength of IR camera light

Rear Truck: 940nm (6 Infrared (IR) LEDS)

Interior IR: 940nm (2 Infrared (IR) LEDS)

Button

EB-1 button: Press the button – manual recording.

Sensor

3-Axis Acceleration Sensor

Battery or Capacitor

Built-in Super Capacitor

Input Power

DC 12V-24V (3 pole DC Plug (Ø3.5 x Ø1.1)) to Wires (Black: GND / Yellow: B+ / Red: ACC)

Power Consumption

Normal Mode (GPS On / 3CH) : Avg. 750mA / 12V

Parking Mode (GPS Off / 3CH) : Avg. 600mA / 12V

*Approx. 40mA increase in current when Interior Camera IR LEDs are ON.

*Approx. 60mA increase in current when Rear Truck Camera IR LEDs are ON.

*Actual power consumption may vary depending on use conditions and environment.

Operation Temperature

-20°C – 70°C (-4°F – 158°F)

Storage Temperature

-20°C − 80°C (-4°F − 176°F)

High Temperature Cut-Off

Approx. 75°C (167°F)

Certifications

Front (with Main unit & EB-1): FCC, IC, CE, UKCA, RCM, WEEE, RoHS

Rear Truck & Interior IR: FCC, IC, CE, UKCA, RCM, WEEE, RoHS, KC

Software

BlackVue Application: Android 8.0 or higher, iOS 13.0 or higher

BlackVue Viewer: Windows 7 or higher, Mac Sierra OS X (10.12) or higher

BlackVue Web Viewer: Chrome 71 or higher, Safari 13.0 or higher

Others

Adaptive Format Free File Management System

Origin

Made in Korea

Warranty

36 Months (Australian Customers Only)

*T&C's Apply
