Getting Started
Everything you need to get started with your DR590X-2CH Plus can be found in the links below.
Getting stuck operating your BlackVue camera or attempting to perform a certain function? Check out our App Support and Camera Support categories which have a collection of detailed how-to guides and troubleshooting available.
Want to know what accessories are compatible with the DR590X-2CH Plus? Check out our Accessory Compatibility List.
 |
|
|
|
|
| DR590X-2CH Plus - Online Quick Start Guide | App Support | Camera Support | Accessory Compatibility List | Frequently Asked Questions |
Firmware
| Latest BlackVue Firmware | |
|
What's new:
※ Compatible software versions: BlackVue App: Android v4.17 / iOS v4.13 and up. BlackVue Viewer: Windows v3.24 / Mac v3.24 and up. FLEETA App: Android v1.17 / iOS v1.14 and up. FLEETA Web Viewer |
Released: 09/01/2026 |
Warranty
All BlackVue cameras purchased in Australia from authorised BlackVue dealers come with a 2-year limited hardware warranty from the original date of purchase, with the option to register your purchase for an additional year of warranty for free via the link below (3-years total).
In the unlikely event you experience a hardware fault with your camera, you can contact your original retailer or raise a warranty or out of warranty claim with us below.
Recording Timetable
| Model | Memory Capacity | Image Quality | Resolution/Recording Time |
| DR590X-2CH Plus | Full HD @30fps + Full HD @30fps | ||
| 32GB | Highest | 2 HR 45 Min | |
| High | 3 HR 15 Min | ||
| Normal | 4 HR 05 Min | ||
| 64GB | Highest | 5 HR 35 Min | |
| High | 6 HR 40 Min | ||
| Normal | 8 HR 15 Min | ||
| 128GB | Highest | 11 HR 15 Min | |
| High | 13 HR 25 Min | ||
| Normal | 16 HR 40 Min | ||
| 256GB | Highest | 22 HR 35 Min | |
| High | 26 HR 55 Min | ||
| Normal | 33 HR 25 Min | ||
| 512GB | Highest | 45 HR 15 Min | |
| High | 54 HR | ||
| Normal | 66 HR 50 Min | ||
| Bitrate (Mbps) Front + Rear | Highest | 12 + 10 | |
| High | 10 + 8 | ||
| Normal | 8 + 6 |
*Actual recording times may vary
Specifications
Model Name |
DR590X-2CH Plus |
Colour / Size / Weight |
Front: Black / Width 111.8 mm x Height 34 mm / 103.5 g Rear: Black / Width 67.4 mm x Height 25 mm / 25.4 g |
Memory |
microSD Card (32 GB / 64 GB / 128 GB / 256 GB / 512 GB) *We only recommend using BlackVue SD cards |
Recording Modes |
Normal recording, Event recording (when impact is detected in normal and parking mode), Manual recording and Parking recording (when motion is detected). *When using Hardwiring Power Cable, ACC+ will trigger parking mode. When using other methods, G-sensor will trigger parking mode. |
Camera |
Front: STARVIS™ CMOS Sensor (Approx. 2.1 M Pixel) Rear: CMOS Sensor (Approx. 2.1 M Pixel) |
Viewing Angle |
Front: Diagonal 131°, Horizonal 107°, Vertical 55° Rear: Diagonal 136.8°, Horizonal 111.3°, Vertical 57.5° |
Resolution / Frame Rate |
Front: Full HD @ 30 fps Rear: Full HD @ 30 fps *Frame rate may vary during Wi-Fi streaming. |
Image Quality |
Highest, High, Normal |
Video Compression Mode |
MP4 |
Wi-Fi |
Built-in (802.11 b.g.n) |
GPS |
External (Optional - Dual Band: GPS, GLONASS) |
Microphone |
Built-in |
Speaker (Voice Guidance) |
Built-in |
LED Indicators |
Front: Recording LED, GPS LED, Wi-Fi LED, Front Security LED Rear: Rear Security LED |
Button |
Wi-Fi Button: Press once to turn on/off Wi-Fi. |
Sensor |
3-Axis Acceleration Sensor |
Battery or Capacitor |
Built-in Super Capacitor |
Input Power |
DC 12V-24V (3 pole DC Plug (Ø3.5 x Ø1.1)) to Wires (Black: GND / Yellow: B+ / Red: ACC) |
Power Consumption |
Normal Mode (Wi-Fi On/GPS On/2CH): Avg. 370mA / 12V Normal Mode (Wi-Fi Off/GPS On/2CH): Avg. 330mA / 12V Parking Mode (Wi-Fi On/GPS Off/2CH): Avg. 340mA / 12V Parking Mode (Wi-Fi Off/GPS Off/2CH): Avg. 300mA / 12V *Actual power consumption may vary depending on use conditions and environment. |
Operation Temperature |
-20°C – 70°C (-4°F – 158°F) |
Storage Temperature |
-20°C – 80°C (-4°F – 176°F) |
High Temperature Cut-Off |
Approx. 70°C (158°F) |
Certifications |
Front: FCC, CE, RoHS, Telec, WEEE, IC, RCM Rear: FCC, CE, RoHS, WEEE |
Software |
BlackVue Application: Android 5.0 or higher, iOS 9.0 or higher BlackVue Viewer: Windows 7 or higher, Mac Yosemite OS X (10.10) or higher |
Others |
Adaptive Format Free File Management System |
Origin |
Made in Korea |
Warranty |
36 Months (Australian Customers Only) *T&C's Apply |
STARVIS is a trademark of Sony Corporation
