Quick links: | ||||
| Getting Started | Firmware | Warranty | Recording Timetable | Specifications |
Getting Started
Everything you need to get started with your DR770X II (1CH / 2CH) can be found in the links below.
Getting stuck operating your BlackVue camera or attempting to perform a certain function? Check out our App Support and Camera Support categories which have a collection of detailed how-to guides and troubleshooting available.
Want to know what accessories are compatible with the DR770X II (1CH / 2CH)? Check out our Accessory Compatibility List.
 |
|
|
|
|
| DR770X II - Quick Start Guide | App Support | Camera Support | Accessory Compatibility List | Frequently Asked Questions |
Firmware
| Latest BlackVue Firmware | |
|
What's new:
※ Compatible software versions: BlackVue App: Android v4.24 / iOS v4.20 and up. BlackVue Viewer: Windows v3.24 / Mac v3.24 and up. FLEETA App: Android v1.24 / iOS v1.22 and up. FLEETA Web Viewer |
Released: 29/04/2026 |
Warranty
All BlackVue cameras purchased in Australia from authorised BlackVue dealers come with a 2-year limited hardware warranty from the original date of purchase, with the option to register your purchase for an additional year of warranty for free via the link below (3-years total).
In the unlikely event you experience a hardware fault with your camera, you can contact your original retailer or raise a warranty or out of warranty claim with us below.
Recording Timetable
| Model | Memory Capacity | Image Quality |
Resolution/Recording Time (Front only) |
Resolution/Recording Time (Front and Rear) |
|
DR770X-1CH II DR770X-2CH II |
Full HD @60fps | Full HD @60fps + Full HD @30fps | ||
| 16GB | Extreme | 1 HR 15 Min | 55 Min | |
| Highest | 2 HR 35 Min | 1 HR 25 Min | ||
| High | 3 HR | 1 HR 50 Min | ||
| Normal | 3 HR 50 Min | 2 HR 20 Min | ||
| 32GB | Extreme | 2 HR 30 Min | 1 HR 50 Min | |
| Highest | 5 HR 10 Min | 2 HR 50 Min | ||
| High | 6 HR | 3 HR 40 Min | ||
| Normal | 7 HR 40 Min | 4 HR 40 Min | ||
| 64GB | Extreme | 5 HR | 3 HR 40 Min | |
| Highest | 10 HR 20 Min | 5 HR 40 Min | ||
| High | 12 HR | 7 HR 20 Min | ||
| Normal | 15 HR 20 Min | 9 HR 20 Min | ||
| 128GB | Extreme | 10 HR | 7 HR 20 Min | |
| Highest | 20 HR 40 Min | 11 HR 20 Min | ||
| High | 24 HR | 15 HR 40 Min | ||
| Normal | 30 HR 40 Min | 18 HR 40 Min | ||
| 256GB | Extreme | 20 HR | 14 HR 40 Min | |
| Highest | 41 HR 20 Min | 22 HR 40 Min | ||
| High | 48 HR | 31 HR 20 Min | ||
| Normal | 61 HR 20 Min | 37 HR 20 Min | ||
| Bitrate (Mbps) Front + Rear | Extreme | 25 | 25 + 10 | |
| Highest | 12 | 12 + 10 | ||
| High | 10 | 10 + 8 | ||
| Normal | 8 | 8 + 6 |
*Actual recording times may vary
Specifications
Model Name |
DR770X-1CH II / DR770X-2CH II |
Colour / Size / Weight |
Front: Black / Width 118.5 mm x Height 36 mm / 104 g Rear: Black / Width 67.4 mm x Height 25 mm / 25 g |
Memory |
microSD Card (64 GB / 128 GB / 256 GB / 512 GB / 1 TB) *We only recommend using BlackVue SD cards |
Recording Modes |
Normal recording, Event recording (when impact is detected in normal and parking mode), Manual recording and Parking recording (when motion is detected). *When using Hardwiring Power Cable, ACC+ will trigger parking mode. When using other methods, G-sensor will trigger parking mode. |
Camera |
Front: STARVISTM CMOS Sensor (Approx. 2.1 M Pixel) Rear: STARVISTM CMOS Sensor (Approx. 2.1 M Pixel) |
Viewing Angle |
Front: Diagonal 139°, Horizonal 116°, Vertical 61° Rear: Diagonal 139°, Horizonal 116°, Vertical 61° |
Resolution / Frame Rate |
Front: Full HD (1920 x 1080) @ 60 fps Rear: Full HD (1920 x 1080) @ 30 fps *Frame rate may vary during Wi-Fi streaming. |
Video Codec |
H.264 (AVC) |
Image Quality (Mbps) |
Highest (Extreme), Highest, High, Normal |
Video Compression Mode |
MP4 |
Wi-Fi |
Built-in (802.11 a.b.g.n.ac) |
GPS |
Built-in (Dual Band: GPS, GLONASS) |
Bluetooth |
Built-in (V2.1+EDR/4.2) |
Microphone |
Built-in |
Speaker (Voice Guidance) |
Built-in |
LED Indicators |
Front: Recording LED, GPS LED, B/W/L (Bluetooth/Wi-Fi/LTE) LED, Front Security LED Rear: Rear Security LED |
Button |
Format Button: Press and hold format button for 5 seconds, and after a beep, release the button. Then, press again and hold for 5 seconds and release the button after a beep to format the microSD card. Touch Sensor: Pressing the touch sensor triggers manual recording depending on the firmware settings. |
Sensor |
3-Axis Acceleration Sensor |
Battery or Capacitor |
Built-in Super Capacitor |
Input Power |
DC 12V-24V (3 pole DC Plug (Ø3.5 x Ø1.1)) to Wires (Black: GND / Yellow: B+ / Red: ACC) |
Power Consumption |
DR770X-2CH II: Normal Mode (GPS On/2CH): Avg. 380mA /12V Parking Mode (GPS Off/2CH): Avg. 300mA /12V *Actual power consumption may vary depending on use conditions and environment. |
|
DR770X-1CH II: Normal Mode (GPS On/1CH): Avg. 240mA /12V Parking Mode (GPS Off/1CH): Avg. 190mA /12V *Actual power consumption may vary depending on use conditions and environment. | |
Operation Temperature |
-20°C − 80°C (-4°F − 176°F) |
Storage Temperature |
-20°C − 80°C (-4°F − 176°F) |
High Temperature Cut-Off |
Approx. 80°C (176°F) |
Certifications |
Front: FCC, ISED, CE, UKCA, RCM, RoHS, Telec, WEEE, KC Rear: FCC, ISED, CE, UKCA, RCM, RoHS, WEEE, KC |
Software |
BlackVue Application: Android 8.0 or higher, iOS 13.0 or higher BlackVue Viewer: Windows 7 or higher, Mac Sierra OS X (10.12) or higher BlackVue Web Viewer: Chrome 71 or higher, Safari 13.0 or higher |
Others |
Adaptive Format Free File Management System |
4G LTE |
Optional via the CM100GLTE module |
Origin |
Made in Korea |
Warranty |
36 Months (Australian Customers Only) *T&C's Apply |
STARVIS is a trademark of Sony Corporation
