Getting Started
Everything you need to get started with your DR750X-1CH can be found in the links below.
Getting stuck operating your BlackVue camera or attempting to perform a certain function? Check out our App Support and Camera Support categories which have a collection of detailed how-to guides and troubleshooting available.
Want to know what accessories are compatible with the DR750X-1CH? Check out our Accessory Compatibility List.
 |
|
|
|
|
| DR750X-1CH - Quick Start Guide | App Support | Camera Support | Accessory Compatibility List | Frequently Asked Questions |
Firmware
| Latest BlackVue Firmware | |
|
What's new:
|
Released: 26/10/2022 |
Warranty
All BlackVue cameras purchased in Australia from authorised BlackVue dealers come with a 2-year limited hardware warranty from the original date of purchase, with the option to register your purchase for an additional year of warranty for free via the link below (3-years total).
In the unlikely event you experience a hardware fault with your camera, you can contact your original retailer or raise a warranty or out of warranty claim with us below.
Recording Timetable
| Model | Memory Capacity | Image Quality | Resolution/Recording Time |
| DR750X-1CH | Full HD @60fps | ||
| 16GB | Extreme | 1 HR 15 Min | |
| Highest | 2 HR 35 Min | ||
| High | 3 HR | ||
| Normal | 3 HR 50 Min | ||
| 32GB | Extreme | 2 HR 30 Min | |
| Highest | 5 HR 10 Min | ||
| High | 6 HR | ||
| Normal | 7 HR 40 Min | ||
| 64GB | Extreme | 5 HR | |
| Highest | 10 HR 20 Min | ||
| High | 12 HR | ||
| Normal | 15 HR 20 Min | ||
| 128GB | Extreme | 10 HR | |
| Highest | 20 HR 40 Min | ||
| High | 24 HR | ||
| Normal | 30 HR 40 Min | ||
| 256GB | Extreme | 20 HR | |
| Highest | 41 HR 20 Min | ||
| High | 48 HR | ||
| Normal | 61 HR 20 Min | ||
| Bitrate (Mbps) Front + Rear | Extreme | 25 | |
| Highest | 12 | ||
| High | 10 | ||
| Normal | 8 |
*Actual recording times may vary
Specifications
Model Name |
DR750X-1CH |
Colour / Size / Weight |
Front: Black / Width 118.5 mm x Height 36 mm / 103 g |
Memory |
microSD Card (32 GB / 64 GB / 128 GB / 256 GB) *We only recommend using BlackVue SD cards |
Recording Modes |
Normal recording, Event recording (when impact is detected in normal and parking mode), Manual recording and Parking recording (when motion is detected). *When using Hardwiring Power Cable, ACC+ will trigger parking mode. When using other methods, G-sensor will trigger parking mode. |
Camera |
STARVIS™ CMOS Sensor (Approx. 2.1 M Pixel) |
Viewing Angle |
Diagonal 139°, Horizonal 116°, Vertical 61° |
Resolution / Frame Rate |
Full HD @ 60 fps *Frame rate may vary during Wi-Fi streaming. |
Image Quality |
Highest (Extreme), Highest, High, Normal |
Video Compression Mode |
MP4 |
Wi-Fi |
Built-in (802.11 b.g.n) |
GPS |
Built-in (Dual Band: GPS, GLONASS) |
Bluetooth |
Built-in (V2.1+EDR/4.2) |
4G LTE |
Optional via the CM100GLTE module |
Microphone |
Built-in |
Speaker (Voice Guidance) |
Built-in |
LED Indicators |
Recording LED, GPS/BT LED, LTE/Wi-Fi LED, Front Security LED, Proximity Sensing indicator LED |
Button |
Wi-Fi Button: Press once to turn on/off Wi-Fi. Proximity Sensor: Touching the proximity sensor turns on/off audio recording or triggers manual recording depending on the firmware settings. |
Sensor |
3-Axis Acceleration Sensor |
Battery or Capacitor |
Built-in Super Capacitor |
Input Power |
DC 12V-24V (3 pole DC Plug (Ø3.5 x Ø1.1)) to Wires (Black: GND / Yellow: B+ / Red: ACC) |
Power Consumption |
Normal Mode (Wi-Fi On/GPS On/1CH): Avg. 275mA / 12V Normal Mode (Wi-Fi Off/GPS On/1CH): Avg. 240mA / 12V Parking Mode (Wi-Fi On/GPS Off/1CH): Avg. 220mA / 12V Parking Mode (Wi-Fi Off/GPS Off/1CH): Avg. 185mA / 12V *Actual power consumption may vary depending on use conditions and environment. |
Operation Temperature |
-20°C − 85°C (-4°F − 185°F) |
Storage Temperature |
-20°C − 90°C (-4°F − 194°F) |
High Temperature Cut-Off |
Approx. 85°C (185°F) |
Certifications |
FCC, CE, RoHS, Telec, WEEE, IC |
Software |
BlackVue Application: Android 5.0 or higher, iOS 9.0 or higher BlackVue Viewer: Windows 7 or higher, Mac Yosemite OS X (10.12) or higher |
Others |
Adaptive Format Free File Management System |
Origin |
Made in Korea |
Warranty |
36 Months (Australian Customers Only) *T&C's Apply |
STARVIS is a trademark of Sony Corporation
