Getting Started
Everything you need to get started with your DR750G Pro (1CH / 2CH) can be found in the links below.
Getting stuck operating your BlackVue camera or attempting to perform a certain function? Check out our App Support and Camera Support categories which have a collection of detailed how-to guides and troubleshooting available.
Want to know what accessories are compatible with the DR750G Pro (1CH / 2CH)? Check out our Accessory Compatibility List.
 |
|
|
|
|
| DR750G Pro - Quick Start Guide | App Support | Camera Support | Accessory Compatibility List | Frequently Asked Questions |
Firmware
| Latest BlackVue Firmware | |
|
What's new:
|
Released: 04/11/2024 |
Warranty
All BlackVue Gold series cameras purchased in Australia from authorised BlackVue dealerships come with a 5-year limited hardware warranty from the original date of purchase, with the option to register your purchase via the link below.
In the unlikely event you experience a hardware fault with your camera, you can contact your original dealership or raise a warranty or out of warranty claim with us below.
Recording Timetable
| Model | Memory Capacity | Image Quality |
Resolution/Recording Time (Front only) |
Resolution/Recording Time (Front and Rear) |
|
DR750G-1CH Pro DR750G-2CH Pro |
Quad HD @30fps | Quad HD @30fps + Full HD @30fps | ||
| 32GB | Extreme | 2 HR 40 Min | 1 HR 50 Min | |
| Highest | 5 HR 30 Min | 2 HR 50 Min | ||
| High | 6 HR 30 Min | 3 HR 40 Min | ||
| Normal | 8 HR | 4 HR 40 Min | ||
| 64GB | Extreme | 5 HR 20 Min | 3 HR 40 Min | |
| Highest | 11 HR | 5 HR 40 Min | ||
| High | 13 HR | 7 HR 20 Min | ||
| Normal | 16 HR | 9 HR 20 Min | ||
| 128GB | Extreme | 10 HR 40 Min | 7 HR 20 Min | |
| Highest | 22 HR | 11 HR 20 Min | ||
| High | 26 HR | 14 HR 40 Min | ||
| Normal | 32 HR | 18 HR 40 Min | ||
| 256GB | Extreme | 21 HR 20 Min | 14 HR 40 Min | |
| Highest | 44 HR | 22 HR 40 Min | ||
| High | 52 HR | 29 HR 20 Min | ||
| Normal | 64 HR | 37 HR 20 Min | ||
| Bitrate (Mbps) Front + Rear | Extreme | 25 | 25 + 10 | |
| Highest | 12 | 12 + 10 | ||
| High | 10 | 10 + 8 | ||
| Normal | 8 | 8 + 6 |
*Actual recording times may vary
Specifications
Model Name |
DR750G-2CH Pro / DR750G-1CH Pro |
Colour / Size / Weight |
Front: Black / Width 118.5 mm x Height 36 mm / 105 g Rear: Black / Width 67.4 mm x Height 25 mm / 25 g |
Memory |
microSD Card (32 GB / 64 GB / 128 GB / 256 GB) *We only recommend using BlackVue SD cards |
Recording Modes |
Normal recording, Event recording (when impact is detected in normal and parking mode), Manual recording (File locked) and Parking recording (when motion is detected) *When using Hardwiring Power Cable, ACC+ will trigger parking mode. When using other methods, G-sensor will trigger parking mode. |
Camera |
Front: 5-Megapixel CMOS Sensor Rear: STARVIS™ CMOS Sensor (Approx. 2.1 M Pixel) |
Viewing Angle |
Front: Diagonal 142°, Horizontal 120°, Vertical 64° Rear: Diagonal 139°, Horizontal 116°, Vertical 61° |
Resolution/Frame Rate |
Front: Quad HD / 2K (2560x1440) @ 30 fps Rear: Full HD (1920x1080) @ 30 fps *Frame rate may vary during Wi-Fi streaming. |
Image Quality |
Highest (Extreme), Highest, High, Normal |
Video Compression Mode |
MP4 |
Wi-Fi |
Built-in (802.11 b.g.n) |
GPS |
Built-in (Dual Band: GPS, GLONASS) |
Bluetooth |
Built-in (V2.1+EDR/4.2) |
4G LTE |
Optional via the CM100GLTE module |
Microphone |
Built-in |
Speaker (Voice Guidance) |
Built-in |
LED Indicators |
Front: Recording LED, GPS/BT LED, LTE/Wi-Fi LED, Front Security LED, Proximity Sensing indicator LED Rear: Rear Security LED |
Button |
Wi-Fi button: Press once to turn on/off Wi-Fi. Press and hold for 5 seconds and once voice instructions start, release the button. Then press once Proximity sensor: Touching the proximity sensor turns on/off audio recording or triggers manual recording (file locked) depending on the firmware settings. |
Sensor |
3-Axis Acceleration Sensor |
Battery or Capacitor |
Built-in Super Capacitor |
Input Power |
DC 12V-24V (DC Plug (Ø3.5 x Ø1.1)) to Wires (Black: GND / Yellow: B+ / Red: ACC) |
Power Consumption |
DR750G-2CH Pro: Normal Mode (Wi-Fi On / GPS On / 2CH) : 380mA / hour Normal Mode (Wi-Fi Off / GPS On / 2CH) : 350mA / hour Parking Mode (Wi-Fi On / GPS Off / 2CH) : 360mA / hour Parking Mode (Wi-Fi Off / GPS Off / 2CH) : 330mA / hour *Actual power consumption may vary depending on use conditions and environment. |
|
DR750G-1CH Pro: Normal Mode (Wi-Fi On / GPS On / 1CH) : 260mA / hour Normal Mode (Wi-Fi Off / GPS On / 1CH) : 225mA / hour Parking Mode (Wi-Fi On / GPS Off / 1CH) : 240mA / hour Parking Mode (Wi-Fi Off / GPS Off / 1CH) : 210mA / hour *Actual power consumption may vary depending on use conditions and environment. | |
Operation Temperature |
-20°C − 85°C (-4°F − 185°F) |
Storage Temperature |
-20°C − 90°C (-4°F − 194°F) |
High Temperature Cut-Off |
Approx. 85°C (185°F) |
Certifications |
Front: RCM Rear: FCC, CE, RoHS, WEEE |
Software |
BlackVue Viewer: Windows 7 or higher and Mac Yosemite OS X (10.10) or higher |
Application |
BlackVue Application: (Android 5.0 or higher, iOS 9.0 or higher) |
Others |
Adaptive Format Free File Management System Advanced Driver Assistance System LDWS (Lane Departure Warning System) FVSA (Forward Vehicle Start Alarm) |
Origin |
Made in Korea |
Warranty |
60 Months Warranty (Dealership Customers Only) *T&C's Apply |
STARVIS is a trademark of Sony Corporation
