Getting Started
Everything you need to get started with your DR770X Box can be found in the links below.
Getting stuck operating your BlackVue camera or attempting to perform a certain function? Check out our App Support and Camera Support categories which have a collection of detailed how-to guides and troubleshooting available.
Want to know what accessories are compatible with the DR770X Box? Check out our Accessory Compatibility List.
 |
|
|
|
|
| DR770X Box - Quick Start Guide | App Support | Camera Support | Accessory Compatibility List | Frequently Asked Questions |
Firmware
| Latest BlackVue Firmware | |
|
What's new:
※ Compatible software versions: BlackVue App: Android v4.19 / iOS v4.15 and up. BlackVue Viewer: Windows v3.24 / Mac v3.24 and up. FLEETA App: Android v1.19 / iOS v1.16 and up. FLEETA Web Viewer |
Released: 02/02/2026 |
Warranty
All BlackVue cameras purchased in Australia from authorised BlackVue dealers come with a 2-year limited hardware warranty from the original date of purchase, with the option to register your purchase for an additional year of warranty for free via the link below (3-years total).
In the unlikely event you experience a hardware fault with your camera, you can contact your original retailer or raise a warranty or out of warranty claim with us below.
Recording Timetable
| Model | Memory Capacity | Image Quality |
Resolution/Recording Time (Front + Rear + Interior) |
| DR770X-Box |
Front: Full HD @60fps Rear: Full HD @30fps Interior: Full HD @30fps |
||
| 64GB | Extreme | 3 HR 40 Min | |
| Highest | 4 HR 20 Min | ||
| High | 4 HR 50 Min | ||
| Normal | 6 HR 10 Min | ||
| 128GB | Extreme | 7 HR 20 Min | |
| Highest | 8 HR 40 Min | ||
| High | 9 HR 40 Min | ||
| Normal | 12 HR 20 Min | ||
| 256GB | Extreme | 14 HR 40 Min | |
| Highest | 17 HR 20 Min | ||
| High | 19 HR 20 Min | ||
| Normal | 24 HR 40 Min | ||
| Bitrate (Mbps) Front + Rear + Interior | Extreme | 16 + 10 + 10 | |
| Highest | 12 + 10 + 10 | ||
| High | 10 + 8 + 8 | ||
| Normal | 8 + 6 + 6 |
*Actual recording times may vary
Specifications
Model Name |
DR770X Box |
Colour / Size / Weight |
Main unit: Black / Length 130.0 mm x Width 101.0 mm x Height 33.0 mm / 209 g Front: Black / Length 62.5 mm x Width 34.3 mm x Height 34.0 mm / 43 g Rear: Black / Length 63.5 mm x Width 32.0 mm x Height 32.0 mm / 33 g Rear Truck: Black / Length 70.4 mm x Width 56.6 mm x Height 36.1 mm / 157 g Interior IR: Black / Length 63.5 mm x Width 32.0 mm x Height 32.0 mm / 34 g EB-1: Black / Length 45.2 mm x Width 42.0 mm x Height 14.5 mm / 23 g |
Memory |
microSD Card (64 GB / 128 GB / 256 GB) *We only recommend using BlackVue SD cards |
Recording Modes |
Normal recording, Event recording (when impact is detected in normal and parking mode), Manual recording and Parking recording (when motion is detected). *When using Hardwiring Power Cable, ACC+ will trigger parking mode. When using other methods, G-sensor will trigger parking mode. |
Camera |
Front: STARVIS™ CMOS Sensor (Approx. 2.1 M Pixel) Rear/Rear Truck: STARVIS™ CMOS Sensor (Approx. 2.1 M Pixel) Interior IR: STARVIS™ CMOS Sensor (Approx. 2.1 M Pixel) |
Viewing Angle |
Front: Diagonal 139°, Horizontal 116°, Vertical 61° Rear/Rear Truck (ERC1): Diagonal 116°, Horizontal 97°, Vertical 51° Interior IR: Diagonal 180°, Horizontal 150°, Vertical 93° |
Resolution / Frame Rate |
Front: Full HD (1920×1080) @ 60 fps Rear/Rear Truck: Full HD (1920×1080) @ 30 fps Interior IR: Full HD (1920×1080) @ 30 fps *Frame rate may vary during Wi-Fi streaming. |
Video Codec |
H.264 (AVC) |
Image Quality (Mbps) |
Extreme: 16 + 10 + 10 Mbps Highest: 12 + 10 + 10 Mbps High: 10 + 8 + 8 Mbps Normal: 8 + 6 +6 Mbps |
Video Compression Mode |
MP4 |
Wi-Fi |
Built-in (802.11 b.g.n) |
GPS |
External (Dual Band: GPS, GLONASS) |
Bluetooth |
Built-in (V2.1+EDR/4.2) |
4G LTE |
Optional via the CM100GLTE module |
Microphone |
Built-in |
Speaker (Voice Guidance) |
Built-in |
LED Indicators |
Main unit: Recording LED, GPS LED, BT/Wi-Fi/LTE LED Front: Front & Rear Security LED Rear: Front & Rear Security LED Rear Truck: none Interior IR: Front & Rear Security LED EB-1: Operating/Battery low voltage LED |
Wavelength of IR camera light |
Rear Truck: 940nm (6 Infrared (IR) LEDS) Interior IR: 940nm (2 Infrared (IR) LEDS) |
Button |
EB-1 button: Press the button – manual recording. |
Sensor |
3-Axis Acceleration Sensor |
Battery or Capacitor |
Built-in Super Capacitor |
Input Power |
DC 12V-24V (3 pole DC Plug (Ø3.5 x Ø1.1)) to Wires (Black: GND / Yellow: B+ / Red: ACC) |
Power Consumption |
Normal Mode (GPS On / 3CH) : Avg. 730mA / 12V Parking Mode (GPS Off / 3CH) : Avg. 610mA / 12V *Approx. 40mA increase in current when Interior Camera IR LEDs are ON. *Approx. 60mA increase in current when Rear Truck Camera IR LEDs are ON. *Actual power consumption may vary depending on use conditions and environment. |
Operation Temperature |
-20°C – 70°C (-4°F – 158°F) |
Storage Temperature |
-20°C − 80°C (-4°F − 176°F) |
High Temperature Cut-Off |
Approx. 80°C (176°F) |
Certifications |
Front (with Main unit & EB-1): FCC, IC, CE, UKCA, RCM, Telec, WEEE, RoHS Rear, Rear Truck & Interior IR: KC, FCC, IC, CE, UKCA, RCM, WEEE, RoHS |
Software |
BlackVue Application: Android 8.0 or higher, iOS 13.0 or higher BlackVue Viewer: Windows 7 or higher, Mac Sierra OS X (10.12) or higher BlackVue Web Viewer: Chrome 71 or higher, Safari 13.0 or higher |
Others |
Adaptive Format Free File Management System |
Origin |
Made in Korea |
Warranty |
36 Months (Australian Customers Only) *T&C's Apply |
STARVIS is a trademark of Sony Corporation
