Getting Started
Everything you need to get started with your DR970X-2CH LTE Plus II can be found in the links below.
Getting stuck operating your BlackVue camera or attempting to perform a certain function? Check out our App Support and Camera Support categories which have a collection of detailed how-to guides and troubleshooting available.
Want to know what accessories are compatible with the DR970X-2CH LTE Plus II? Check out our Accessory Compatibility List.
 |
|
|
|
|
| DR970X-2CH LTE Plus II - Quick Start Guide | App Support | Camera Support | Accessory Compatibility List | Frequently Asked Questions |
Firmware
| Latest BlackVue Firmware | |
|
What's new:
※ Compatible software versions: BlackVue App: Android v4.24 / iOS v4.20 and up. BlackVue Viewer: Windows v3.24 / Mac v3.24 and up. FLEETA App: Android v1.24 / iOS v1.22 and up. FLEETA Web Viewer |
Released: 29/04/2026 |
Warranty
All BlackVue cameras purchased in Australia from authorised BlackVue dealers come with a 2-year limited hardware warranty from the original date of purchase, with the option to register your purchase for an additional year of warranty for free via the link below (3-years total).
In the unlikely event you experience a hardware fault with your camera, you can contact your original retailer or raise a warranty or out of warranty claim with us below.
Access Point Names (APN) (AU)
When setting up your DR970X-2CH LTE Plus II camera for the BlackVue cloud, you will need to enter the APN for your SIM card carriers mobile network. A compiled list of common APN names for Australian mobile network providers can be found below. If your carriers APN name is not listed below, please contact your network carrier to find their APN name:
Network Carrier: |
APN Name: |
Telstra |
'telstra.wap' or 'telstra.internet' |
Optus |
'yesinternet' or 'connect' |
Vodafone |
'live.vodafone.com' |
Coles Mobile |
'yesinternet' |
Amaysim |
'yesinternet' |
Aldi Mobile |
'mdata.net.au' |
Kogan Mobile |
'live.vodafone.com' |
Woolworths Mobile |
'mdata.net.au' or 'telstra.internet' |
Boost Mobile |
'telstra.wap' |
Dodo |
'internet' |
iiNet |
'live.vodafone.com' |
E.Tel Mobile |
'yesinternet' |
Note: the DR970X-2CH LTE Plus II is not compatible with Belong mobile
Recording Timetable
| Model | Memory Capacity | Image Quality | Resolution/Recording Time |
| DR970X-2CH LTE Plus II | 4K UHD @30fps + Full HD @30fps | ||
| 64GB | Extreme (H.265) | 1 Hr 50 Min | |
| Extreme (H.264) | 2 Hr 35 Min | ||
| Highest | 3 Hr 40 Min | ||
| High | 6 Hr 05 Min | ||
| Normal | 8 Hr 15 Min | ||
| 128GB | Extreme (H.265) | 3 Hr 45Min | |
| Extreme (H.264) | 5 Hr 15 Min | ||
| Highest | 7 Hr 20 Min | ||
| High | 12 Hr 15 Min | ||
| Normal | 16 Hr 40 Min | ||
| 256GB | Extreme (H.265) | 7 Hr 40 Min | |
| Extreme (H.264) | 10 Hr 35 Min | ||
| Highest | 14 Hr 50 Min | ||
| High | 24 Hr 35 Min | ||
| Normal | 33 Hr 25 Min | ||
| 512GB | Extreme (H.265) | 15 HR 20 Min | |
| Extreme (H.264) | 21 HR 15 Min | ||
| Highest | 29 HR 40 Min | ||
| High | 49 HR 15 Min | ||
| Normal | 66 HR 50 Min | ||
| Bitrate (Mbps) Front + Rear | Extreme (H.265) | 60 + 10 | |
| Extreme (H.264) | 40 + 10 | ||
| Highest | 25 + 10 | ||
| High | 12 + 8 | ||
| Normal | 8 + 6 |
*Actual recording times may vary
Specifications
Model Name |
DR970X-2CH LTE Plus II |
LTE |
Built-in 4G LTE module compatible with nano SIM |
Colour / Size / Weight |
Front: Black / 137.6 (L) x 60.3 (W) x 43 (H) mm / 166 g Rear: Black / 67.3 (L) x 28 (W) x 25 (H) mm / 25 g |
Memory |
microSD Card (64 GB / 128 GB / 256 GB / 512 GB / 1 TB) *We only recommend using BlackVue SD cards |
Recording Modes |
Normal recording, Event recording (when impact is detected in normal and parking mode), Manual recording and Parking recording (when motion is detected). *When using Hardwiring Power Cable, ACC+ will trigger parking mode. When using other methods, G-sensor will trigger parking mode. |
Camera |
Front: STARVISTM 2 CMOS Sensor (Approx. 8.4 M Pixel) Rear: STARVISTM CMOS Sensor (Approx. 2.1 M Pixel) |
Viewing Angle |
Front: Diagonal 146°, Horizonal 125°, Vertical 68° Rear: Diagonal 131°, Horizonal 107°, Vertical 55° |
Resolution / Frame Rate |
Front: 4K (3840 x 2160) @ 30 fps Rear: Full HD (1920 x 1080) @ 30 fps *Frame rate may vary during Wi-Fi streaming. |
Video Codec |
H.265 (HEVC) / H.264 (AVC) |
Image Quality (Mbps) |
Front: Extreme (60), Highest (25), High (12), Normal (8) Rear: Extreme (10), Highest (10), High (8), Normal (6) *60Mbps bitrates only support in H.265(HEVC). |
Video Compression Mode |
MP4 |
Wi-Fi |
Built-in (802.11 a.b.g.n.ac) |
Bluetooth |
Built-in (V2.1+EDR/4.2) |
GPS |
Built-in (Dual Band : GPS, GLONASS) |
Microphone |
Built-in |
Speaker (Voice Guidance) |
Built-in |
LED Indicators |
Front: Recording LED, GPS LED, B/W/L (Bluetooth/Wi-Fi/LTE) LED, Front Security LED Rear: Rear Security LED |
Sensor |
3-Axis Acceleration Sensor |
Button |
Touch Sensor: Pressing the touch sensor triggers manual recording depending on the firmware settings. |
Battery or Capacitor |
Built-in Super Capacitor |
Input Power |
DC 12V-24V (3 pole DC Plug (Ø3.5 x Ø1.1)) to Wires (Black: GND / Yellow: B+ / Red: ACC) |
Power Consumption |
Normal Mode (GPS On/Cloud On): Avg. 590mA/12V Normal Mode (GPS On/Cloud Off): Avg. 530mA/12V Parking Mode (GPS Off/Cloud On): Avg. 430mA/12V Parking Mode (GPS Off/Cloud Off): Avg. 370mA/12V *Actual power consumption may vary depending on use conditions and environment. *Model DR970X-2CH LTE Plus II should be used only in circuits that satisfy Limited Power Source. (Maximum power consumption is to be less than 100 VA or 8 A). |
Operation Temperature |
-20°C − 70°C (-4°F − 158°F) |
Storage Temperature |
-20°C − 70°C (-4°F − 158°F) |
High Temperature Cut-Off |
Approx. 70°C (158°F) |
Certifications |
Front: FCC, ISED, CE, UKCA, RCM, Telec, RoHS, WEEE, KC Rear: FCC, ISED, CE, UKCA, RCM, RoHS, WEEE, KC |
Software |
BlackVue Application: Android 8.0 or higher, iOS 13.0 or higher BlackVue Viewer: Windows 7 or higher, Mac Sierra OS X (10.12) or higher BlackVue Web Viewer: Chrome 71 or higher, Safari 13.0 or higher |
Others |
Adaptive Format Free File Management System |
Origin |
Made in Korea |
Warranty |
36 Months (Australian Customers Only) *T&C's Apply |
STARVIS is a trademark of Sony Corporation
