Quick links: | ||||
| Firmware | Warranty | Recording Timetable | Specifications | |
Getting Started
Everything you need to get started with your ELITE 9 can be found in the links below.
Getting stuck operating your BlackVue camera or attempting to perform a certain function? Check out our App Support and Camera Support categories which have a collection of detailed how-to guides and troubleshooting available.
Want to know what accessories are compatible with the ELITE 9? Check out our Accessory Compatibility List.
 |
|
|
|
|
| ELITE 9 - Online Product Manual | App Support | Camera Support | Accessory Compatibility List | Frequently Asked Questions |
Firmware
| Latest BlackVue Firmware | |
|
What's new:
※ Compatible software versions: BlackVue App: Android v4.25 / iOS v4.22 and up. BlackVue Viewer: Windows v3.24 / Mac v3.24 and up. FLEETA App: Android v1.25 / iOS v1.24 and up. FLEETA Web Viewer |
Released: 11/06/2026 |
Warranty
All BlackVue cameras purchased in Australia from authorised BlackVue dealers come with a 2-year limited hardware warranty from the original date of purchase, with the option to register your purchase for an additional year of warranty for free via the link below (3-years total).
In the unlikely event you experience a hardware fault with your camera, you can contact your original retailer or raise a warranty or out of warranty claim with us below.
Recording Timetable
| Model | Memory Capacity | Image Quality |
Resolution/Recording Time (Front only) |
Resolution/Recording Time (Front & Rear) |
| ELITE 9 | 4K QHD @30fps | 4K QHD @30fps + 2K QHD @30fps | ||
| 64GB | Extreme (H.256) | 2 HR | 1 HR 20 Min | |
| Extreme (H.254) | 3 HR | 1 HR 50 Min | ||
| High | 4 HR 10 Min | 2 HR 25 Min | ||
| Medium | 6 HR | 3 HR 20 Min | ||
| Low | 11 HR 25 Min | 5 HR 40 Min | ||
| 128GB | Extreme (H.265) | 4 HR 10 Min | 2 HR 50 Min | |
| Extreme (H.254) | 6 HR 10 Min | 3 HR 45 Min | ||
| High | 8 HR 20 Min | 4 HR 55 Min | ||
| Medium | 12 HR 05 Min | 6 HR 50 Min | ||
| Low | 23 HR | 12 HR 25 Min | ||
| 256GB | Extreme (H.265) | 8 HR 25 Min | 5 HR 55 Min | |
| Extreme (H.254) | 12 HR 35 Min | 7 HR 40 Min | ||
| High | 16 HR 50 Min | 10 HR | ||
| Medium | 24 HR 20 Min | 13 HR 50 Min | ||
| Low | 46 HR | 23 HR | ||
| 512GB | Extreme (H.265) | 17 HR 05 Min | 12 HR | |
| Extreme (H.254) | 25 HR 35 Min | 15 HR 35 Min | ||
| High | 34 HR 15 Min | 20 HR 30 Min | ||
| Medium | 49 HR 25 Min | 28 HR 05 Min | ||
| Low | 93 HR 20 Min | 46 HR 30 Min | ||
| 1TB | Extreme (H.265) | 34 HR 30 Min | 25 HR 20 Min | |
| Extreme (H.254) | 51 HR 24 Min | 31 HR 30 Min | ||
| High | 68 HR 45 Min | 41 HR 15 Min | ||
| Medium | 99 HR | 56 HR 30 Min | ||
| Low | 186 HR 40 Min | 93 HR 20 Min | ||
| Bitrate (Mbps) Front + Rear | Extreme (H.265) | 60 | 60 + 25 | |
| Extreme (H.264) | 40 | 40 + 25 | ||
| High (Default) | 30 | 30 + 20 | ||
| Medium | 20 | 20 + 15 | ||
| Low | 10 | 10 + 10 |
*Actual recording times may vary
Specifications
Key Specifications | |
Model Name |
ELITE 9-1CH | ELITE 9-2CH |
Colour / Size / Weight |
Front: Black (Point colour: Rose Gold) / Length: 129.7mm x Height 55.3mm / 195g Rear: Black / Width: 29mm x Height 39.1mm / 38.8g |
Image Sensor |
Front and Rear: STARVIS™ 2 (Approx. 5 M Pixel) |
Lens |
Front: F/1.7, 7G+1IR Rear: F/2.0, 6G+1IR |
Viewing Angle |
Front: Diagonal 146° , Horizontal 125°, Vertical 68° Rear: Diagonal 142° , Horizontal 118°, Vertical 62° |
Resolution/Frame Rate |
Front: 4K UHD @ 30fps Rear: 2K QHD @ 30 fps *Frame rate may vary during Wi-Fi streaming |
HDR |
Front and Rear (Dual HDR) |
Video Codec |
H.265 (HEVC), H.264 (AVC) |
Image Quality |
Extreme, High, Medium, Low |
Memory |
microSD Card (64 GB / 128 GB / 256 GB / 512 GB / 1 TB) *We only recommend using BlackVue SD cards |
LED Indicators |
Front: Recording status, GPS connectivity, A/C (App/Cloud) connectivity Rear: Rear security LED |
Smart Event Recording |
Driving Impact Parking Impact* Overspeed Hard Acceleration Hard Braking Hard Cornering (Including 10 sec. Pre-Event buffer) *Buffered recording is not supported in Power Saving Mode. |
Parking Mode |
Motion Detection Time Lapse Power Saving (<1mA)* *Buffered recording is not supported. |
Protection Systems |
Low Voltage Cut-Off: Passenger Vehicle 11.8~12.5V or Heavy Vehicle 22.8~24V Timer Cut-Off: 1~48H High Temperature Cut-Off: Approx. 75°C (167°F) |
Event File Overwrite Protection |
Yes (up to 50) |
Video File Extension |
MP4 |
Wi-Fi |
Built-in Wi-Fi 5 (802.11a/b/g/n/ac) Supports both 2.4GHz and 5GHz bands |
Bluetooth |
Built-in (V2.1+EDR / 5.3) |
GPS |
Built-in (Dual Band: GPS, GLONASS) |
Speaker & Microphone |
Built-in |
G-Sensor |
3-Axis Acceleration Sensor |
Button |
Power Button: Press and hold for 3 seconds to Power off. Press once to power on.* Touch Sensor: Pressing the touch sensor triggers manual recording depending on the firmware settings. *The camera cannot be powered on while the vehicle’s ACC is off. |
Battery or Capacitor |
Built-in Super Capacitor Capacitor's are not at risk of heat damage which batteries face |
Input Power |
DC 12V-24V (DC Plug (Ø3.5 x Ø1.1)) to Wires (Black: GND / Yellow: B+ / Red: ACC) |
Power Consumption |
ELITE 9-1CH: Normal Mode (GPS On/1CH): Avg. 320mA /12V Parking Mode (GPS Off/1CH): Avg. 260mA /12V Power Saving Mode: Avg. <1mA / 12V * Actual power consumption may vary depending on use conditions and environment. |
|
ELITE 9-2CH: Normal Mode (GPS On / 2CH): Avg. 460mA / 12V Parking Mode (GPS Off / 2CH): Avg. 360mA / 12V Power Saving Mode: Avg. <1mA / 12V * Actual power consumption may vary depending on use conditions and environment. | |
Operating Temperature |
-20°C − 65°C (-4°F − 149°F) |
Storage Temperature |
-20°C − 80°C (-4°F − 176°F) |
App |
BlackVue App: Android 10.0 or higher, iOS 15.0 or higher FLEETA App: Android 10.0 or higher, iOS 15.0 or higher |
Software |
BlackVue Viewer: Windows 7 or higher, Mac Sierra OS X (10.12) or higher FLEETA Web Viewer: Chrome (Windows), Edge, Safari (Mac) |
Firmware Language |
Supports 17 Languages: Korean(한국어) / English(English) / Russian(Русский) / Japanese(日本語) Simplified Chinese(中文) / German(Deutsch) / French(Français) / Thai(ไทย) Indonesian(Bahasa Indonesia) / Vietnamese(Tiếng Việt) / Spanish(Español) Italian(Italiano) / Dutch(Nederlands) / Polish / Norwegian / Finnish / Arabic(عربى) |
Certifications |
Front: Telec, IC(ISED), CE, FCC, RCM, RoHS, WEEE Rear: FCC, IC(ISED), CE, RoHS, WEEE |
Other | |
SD Card Failure Alert |
Yes |
Scheduled Reboot |
Yes |
Format Free |
Yes (Adaptive) |
4G LTE |
Optional via the CM100GLTE module |
Origin |
Made in Korea |
Warranty |
36 Months Warranty (Australian Customers Only) T&C's Apply |
STARVIS is a trademark of Sony Corporation
