Getting Started
Everything you need to get started with your DR650S-2CH can be found in the links below.
Getting stuck operating your BlackVue camera or attempting to perform a certain function? Check out our App Support and Camera Support categories which have a collection of detailed how-to guides and troubleshooting available.
Want to know what accessories are compatible with the DR650S-2CH? Check out our Accessory Compatibility List.
Firmware
Latest BlackVue Firmware |
|
|
What's new:
|
Released: 10/06/2019 |
Latest BlackVue Firmware - R100 Review Kit Compatible |
|
|
What's new:
|
BlackVue Firmware - R100 Rearview Kit compatible (V1.004) Released: 25/11/2016 |
Previous BlackVue Firmware |
|
Warranty
All BlackVue cameras purchased in Australia from authorised BlackVue dealers come with a 2-year limited hardware warranty from the original date of purchase, with the option to register your purchase for an additional year of warranty for free via the link below (3-years total).
In the unlikely event you experience a hardware fault with your camera, you can contact your original retailer or raise a warranty or out of warranty claim with us below.
Recording Timetable
| Memory Capacity | Image Quality | Full HD + HD @30fps | Full HD + HD @15fps | HD + HD @30fps | HD + HD @15fps | |
| 16GB | Highest | 2 HR 10 Min | 2 HR 40 Min | 2 HR 30 Min | 3 HR 10 Min | |
| High | 2 HR 40 Min | 3 HR 30 Min | 3 HR 10 Min | 3 HR 50 Min | ||
| Normal | 3 HR 30 Min | 5 HR 10 Min | 4 HR 30 Min | 5 HR 10 Min | ||
| 32GB | Highest | 4 HR 20 Min | 5 HR 20 Min | 5 HR | 6 HR 20 Min | |
| High | 5 HR 20 Min | 7 HR | 6 HR 20 Min | 7 HR 40 Min | ||
| Normal | 7 HR | 10 HR 20 Min | 9 HR | 10 HR 20 Min | ||
| 64GB | Highest | 8 HR 40 Min | 10 HR 40 Min | 10 HR | 12 HR 40 Min | |
| High | 10 HR 40 Min | 14 HR | 12 HR 40 Min | 15 HR 20 Min | ||
| Normal | 14 HR | 20 HR 40 Min | 18 HR | 20 HR 40 Min | ||
| 128GB | Highest | 17 HR 20 Min | 21 HR 20 Min | 20 HR | 25 HR 20 Min | |
| High | 21 HR 20 Min | 28 HR | 25 HR 20 Min | 30 HR 40 Min | ||
| Normal | 28 HR | 41 HR 20 Min | 36 HR | 41 HR 20 Min | ||
| Bit Rate | Front | Highest | 10 Mbps | 8 Mbps | 8 Mbps | 6 Mbps |
| High | 8 Mbps | 6 Mbps | 6 Mbps | 5 Mbps | ||
| Normal | 6 Mbps | 4 Mbps | 4 Mbps | 4 Mbps | ||
| Rear | Highest | 5 Mbps | 4 Mbps | 5 Mbps | 4 Mbps | |
| High | 4 Mbps | 3 Mbps | 4 Mbps | 3 Mbps | ||
| Normal | 3 Mbps | 2 Mbps | 3 Mbps | 2 Mbps | ||
*Actual recording times may vary
Specifications
Model Name |
DR650S-2CH |
Colour / Size / Weight |
Front: Black / Width 118.5 mm x Height 36 mm / 96 g Rear: Black / Width 67.4mm x Height 25mm / 28 g |
Memory |
microSD Card (16 GB / 32 GB / 64 GB / 128 GB) *We only recommend using BlackVue SD cards |
Recording Mode |
Normal Recording, Event Recording (Impact Detection), and Parking Mode Recording (Motion + Impact Detection) *For Parking mode recording, a Parking Mode Battery Pack (Power Magic Battery Pack) or a Parking Mode Hardwiring Kit (Power Magic Pro) is required. |
Camera |
Front: CMOS Sensor (Approx. 2.1M Pixel) Rear: CMOS Sensor (Approx. 1M Pixel) |
Viewing Angle |
Front: Opposite Angle 129°, Horizontal 103°, Vertical 77° Rear: Opposite Angle 129°, Horizontal 108°, Vertical 57° |
Resolution / Frame |
Front: Full HD (1920x1080) @ 30 fps Rear: HD (1280x720) @ 30 fps * Resolution/frame rate can be changed. * Frame rate is different during Parking mode and Wi-Fi streaming. |
Image Quality |
Highest, High, Normal |
Video Compression Mode |
MP4 |
Wi-Fi |
Built-in (802.11b/g/n(2.4~2.4835GHz)) |
GPS |
Built-in |
Microphone |
Built-in |
Speaker (Voice Guidance) |
Built-in |
LED Indicators |
Front: Recording LED, GPS LED, Wi-Fi LED, Front Security LED Rear: Rear Security LED |
Sensor |
3-Axis Acceleration Sensor |
Button |
Wi-Fi / Format Button * Self-format Function: Press it for 10 seconds to format the microSD card. Voice recording proximity sensor * Touch the button or it recognizes when a hand approaches to within about 2 cm. |
Sensor |
3-Axis Acceleration Sensor |
Battery or Capacitor |
Built-in Super Capacitor |
Input Power |
DC 12 V − 24 V (DC Plug: (Ø3.5 x Ø1.35), MAX 1 A/12 V) |
Current Consumption |
Avg. 400 mA (4.8 W at 12 V, when GPS and Wi-Fi is On) Avg. 300 mA (3.6 W at 12 V, when GPS and Wi-Fi is Off) * Actual power consumption may vary depending on use conditions and environment. |
Operation Temperature |
-20°C − 60°C (-4 °F − 140°F) |
Storage Temperature |
-20°C − 70°C (-4 °F − 158°F) |
Certificates |
Front: FCC, CE, RoHS, Telec, RCM, WEEE Rear: FCC, CE, RoHS, RCM, WEEE |
Software |
BlackVue Viewer: Windows XP or higher (Windows 8 supported) and Mac Leopard OS X (10.5) or higher |
Application |
BlackVue Application (Android 4.4.2 or higher, iOS 8.0 or higher) |
Origin |
Made in Korea |
Warranty |
36 Months (Australian Customers Only) *T&C's Apply |
