Getting Started
Everything you need to get started with your DR600GW-HD can be found in the links below.
Getting stuck operating your BlackVue camera or attempting to perform a certain function? Check out our App Support and Camera Support categories which have a collection of detailed how-to guides and troubleshooting available.
Want to know what accessories are compatible with the DR600GW-HD? Check out our Accessory Compatibility List.
Firmware
Latest BlackVue Firmware |
|
|
What's new:
|
Released: 11/03/2015 |
Previous BlackVue Firmware |
|
None Available |
|
Warranty
All BlackVue cameras purchased in Australia from authorised BlackVue dealers come with a 2-year limited hardware warranty from the original date of purchase, with the option to register your purchase for an additional year of warranty for free via the link below (3-years total).
In the unlikely event you experience a hardware fault with your camera, you can contact your original retailer or raise a warranty or out of warranty claim with us below.
Recording Timetable
| Memory Capacity | Image Quality | Full HD (1920x1080) 30fps | Full HD (1920x1080) 15fps | HD (1280x720) 30fps | HD (1280x720) 15fps | D1 (720x480) 30fps |
| 16GB | Highest | 3 HR 20 Min | 4 HR 10 Min | 4 HR 10 Min | 5 HR 40 Min | 8 HR 30 Min |
| High | 4 HR 30 Min | 5 HR 40 Min | 5 HR 40 Min | 8 HR 30 Min | 11 HR 20 Min | |
| Normal | 6 HR 50 Min | 8 HR 30 Min | 8 HR 40 Min | 11 HR 20 Min | 17 HR 10 Min | |
| Normal (low-end compatible) | 4 HR 30 Min | 6 HR 50 Min | 6 HR 50 Min | 11 HR 20 Min | 17 HR 10 Min | |
| 32GB | Highest | 6 HR 40 Min | 8 HR 20 Min | 8 HR 20 Min | 11 HR 10 Min | 16 HR 50 Min |
| High | 9 HR | 11 HR 10 Min | 11 HR 10 Min | 16 HR 50 Min | 22 HR 30 Min | |
| Normal | 13 HR 30 Min | 16 HR 50 Min | 17 HR | 22 HR 30 Min | 33 HR 50 Min | |
| Normal (low-end compatible) | 9 HR 10 Min | 13 HR 30 Min | 13 HR 40 Min | 22 HR 40 Min | 33 HR 50 Min | |
| 64GB | Highest | 13 HR 20 Min | 16 HR 40 Min | 16 HR 40 Min | 22 HR 20 Min | 33 HR 40 Min |
| High | 18 HR | 22 HR 20 Min | 22 HR 20 Min | 33 HR 40 Min | 43 HR | |
| Normal | 27 HR | 33 HR 40 Min | 33 HR 40 Min | 43 HR | 67 HR 40 Min | |
| Normal (low-end compatible) | 18 HR 20 Min | 27 HR | 27 HR | 43 HR 20 Min | 67 HR 40 Min | |
| Bit Rate | Highest | 10 Mbps | 8 Mbps | 8 Mbps | 6 Mbps | 4 Mbps |
| High | 7.5 Mbps | 6 Mbps | 6 Mbps | 4 Mbps | 3 Mbps | |
| Normal | 5 Mbps | 4 Mbps | 4 Mbps | 3 Mbps | 2 Mbps | |
| Normal (low-end compatible) | 7.5 Mbps | 5 Mbps | 5 Mbps | 3 Mbps | 2 Mbps |
*Actual recording times may vary
LED Indicators
State / LED |
Recording (REC) |
GPS |
Wi-Fi |
Security |
|
Boot-up |
Blinking |
||||
Recording |
Normal |
Orange Blinking |
|
|
White Blinking |
Event |
Red Blinking |
|
|
Fast White Blinking |
|
Parking |
Green Blinking |
|
|
White Blinking |
|
Wi-Fi On |
|
|
Light |
White Blinking |
|
Wi-Fi On/Off Change |
|
|
Blinking |
|
|
GPS On |
|
Blue Light |
|
White Blinking |
|
Software Control |
Available |
Unavailable |
Unavailable |
Available |
|
Specifications
Model Name |
DR600GW-HD |
Colour / Size / Weight |
Black / Width 118.5 mm x Height 36 mm / 114 g |
Memory |
microSD Card (16 GB / 32 GB / 64 GB) *We only recommend using BlackVue SD cards |
Recording Mode |
Normal Recording, Event Recording (Impact Detection), and Parking Mode Recording (Motion + Impact Detection) ❈ For parking mode recording, a battery discharge prevention device is required. |
Camera |
CMOS Sensor (Approx. 2M Pixel) |
Viewing Angle |
Opposite Angle 133, Horizontal 107°, Vertical 80° |
Resolution / Frame |
Full HD (1920x1080) @ 30fps Full HD (1920x1080) @ 15fps HD (1280x720) @ 30fps HD (1280x720) @ 15fps D1 (720x480) @ 30fps ❈ Resolution/frame can be changed |
Video Compression Mode |
MP4 |
Wi-Fi |
Built-in (802.11b/g/n(2.4~2.4835GHz)) |
GPS |
Built-in |
Microphone |
Built-in |
Speaker |
Built-in ❈ Voice Directions |
LED Indicators |
Recording LED, GPS LED, Wi-Fi LED, Security LED |
Sensor |
3-Axis Acceleration Sensor |
Button |
Wi-Fi on/off Button ❈ Self-format Function: Press it for 10 seconds to format the microSD card Voice on/off Button ❈ The proximity sensor is built-in so that voice recording can be turned on/off by approaching it with a hand ❈ Touch the button or it recognizes when a hand approaches to within about 2 cm |
Battery or Capacitor |
Built-in Super Capacitor |
Input Power |
DC 12V-24V |
Current Consumption |
Max. 3.3 W ❈ Varies depending on Wi-Fi usage |
Operation Temperature |
-20°C ~ 70°C |
Certificates |
KC, FCC, CE, RoHS, Telec, WEEE |
Software |
BlackVue Viewer Program (Windows XP or later & Mac Leopard OS (10.5) or later) |
Application |
BlackVue App (Android 2.3 or later & iOS 5.0 or later & Windows 8.0 or later) |
Origin |
Made in Korea |
